status: superseded date: 2026-04-14 supersedes: docs/decisions/002-confluence-page-mapping.md (§"Option A: flat" layout decision; everything else in ADR-002 remains valid)

Superseded by ADR-008 (URL-shape change in v0.10.0) and the v0.9.0 architecture pivot. The FUSE-era nested mount (crates/reposix-fuse/src/{fs,tree,inode}.rs) no longer exists.

ADR-003: Nested mount layout — pages/ + tree/ symlinks for Confluence hierarchy

  • Status: Superseded (was Accepted)
  • Date: 2026-04-14
  • Deciders: reposix core team (overnight session 4)
  • Supersedes: ADR-002 §"Options" layout decision — the flat-layout choice only. The field-mapping, auth-decision, pagination-decision, and rate-limit-decision sections of ADR-002 remain authoritative.
  • Superseded by: none
  • Scope: the FUSE mount root layout emitted by reposix-fuse for any IssueBackend implementation (sim, GitHub, Confluence, future adapters). Code lives in crates/reposix-fuse/src/{fs.rs,tree.rs,inode.rs} and crates/reposix-core/src/path.rs.

Context

ADR-002 chose a flat <padded-id>.md layout at the FUSE mount root for the initial Confluence adapter (Phase 11). That shipped as v0.3 and proved the read-path works, but left a gap: Confluence is natively hierarchical — every page has a parentId — and ls mount/ hides that structure. HANDOFF.md OP-1 ("folder structure inside the mount") identifies this as the next user-visible win, and the hero image has been advertising the tree-like UX since v0.1.

The original design options from ADR-002 §Options were:

  • (A) Flat — what v0.3 shipped. One directory, <padded-id>.md siblings.
  • (B) PageBackend trait — a new backend-shape carrying recursive nodes. Correct long-term but weeks of work across every consumer.
  • (C) parent_id: Option<IssueId> on the core Issue — rejected in ADR-002 because "a field defined for one backend and ignored by others is worse than an explicit ADR about lost metadata."

Phase 13 reopens the decision with new information: the symlink overlay pattern below makes option (C) actually cheap — FUSE synthesizes the tree itself, no new trait, no duplicate content. The cost is one capability bit on the existing IssueBackend trait plus an optional field on Issue.

Phase 13 resolves the layout question with Option (D): pages/ bucket + tree/ symlink overlay. One writable bucket keyed by the stable numeric id. One synthesized read-only overlay of FUSE symlinks at human-readable slug paths. Merge-conflict semantics stay sane because the canonical target path never changes.

Decision

At the mount root, readdir emits three entries:

  1. <root_collection>/ — writable bucket. pages/ for Confluence, issues/ for sim and GitHub. Determined by a new trait method IssueBackend::root_collection_name() -> &'static str (default "issues", Confluence overrides to "pages"). Every canonical <padded-id>.md lives here; this is the sole writable, git-tracked path.
  2. tree/ — synthesized read-only directory, emitted iff the backend reports supports(BackendFeature::Hierarchy) or any loaded issue has parent_id.is_some(). Contains FUSE symlinks at slug paths reflecting the parentId graph. Not emitted for sim or GitHub.
  3. .gitignore — synthesized read-only file, always present, contents /tree/\n (7 bytes). Keeps the derived overlay out of git add / git push.

Symlinks in tree/ dissolve the merge-conflict problem: title renames, reparenting, and sibling reshuffles only move or rename the symlinks. The writable target is always the stable numeric-id path. Git diffs only surface real body edits. Two-agent concurrent edits collapse to standard body-content merges on a single stable file.

Trade-off accepted

Hard-linking or bind-mounting would give the same UX without kernel path-resolution overhead, but FUSE symlinks cost exactly one extra readlink round-trip per access and require zero special cases in the write path. We picked the cheaper-to-implement path.

Alternatives rejected

  • Duplicate-content directories (each page rendered once under pages/<id>.md and again under tree/<slug>.md). Rejected: doubles the writable surface; every edit would need dual-write with conflict resolution, and the whole point of this design is to keep the writable substrate single-source-of-truth.
  • ID-only tree paths (tree/00000360556/00000131192.md). Rejected: indistinguishable from the flat view, loses the ergonomic win that makes cd into a wiki worthwhile.
  • Git-tracked tree/ (no .gitignore emission). Rejected: every title rename or reparent would show up as a massive symlink churn in git status and would dominate git diff. The whole point of the stable-id canonical path is that git only sees real body edits.

Slug algorithm

Implemented as reposix_core::path::slugify_title(&str) -> String:

  1. Unicode-lowercase.
  2. Replace every run of non-[a-z0-9] bytes (including multi-byte UTF-8) with a single -.
  3. Trim leading/trailing -.
  4. Byte-truncate to 60 on a UTF-8 char boundary.
  5. If the result is empty / . / .. / all--, slug_or_fallback falls back to page-<11-digit-padded-id>.

The 60-byte limit fits ext4 NAME_MAX (255) with ample room for collision suffixes (-NN). 11-digit padding matches the existing <padded-id>.md convention under <root_collection>/.

Collision resolution

When two siblings under the same parent produce the same slug, group by slug → sort by ascending IssueId → the first keeps the bare slug, the Nth gets suffix -N (2, 3, 4, ...). Deterministic across mounts without embedding the numeric id in the common case. Tested by nested_layout_collision_gets_suffixed in crates/reposix-fuse/tests/nested_layout.rs.

Cycle handling

Confluence's data model forbids parent cycles, but adversarial seed data or a backend bug could produce one. TreeSnapshot::build runs an iterative DFS with a visited-set; if it finds a cycle, it breaks at the deepest repeated ancestor, emits a tracing::warn!, and treats the cycle-break node as an orphan root. The mount stays usable under a 5s open budget and a 3s readdir budget — proven by nested_layout_cycle_does_not_hang in the FUSE integration tests.

_self.md convention

A page with ≥1 child materializes as a directory named by the parent's slug. POSIX forbids a dir and a file with the same name in one parent, so the parent's own body is exposed as a symlink _self.md inside its own directory. _self is reserved by construction — step 2 of the slug algorithm strips the leading _ to -, so slugify_title can never emit _self.

Concretely, the REPOSIX demo space renders as:

tree/
└── reposix-demo-space-home/
    ├── _self.md                 -> ../../pages/00000360556.md
    ├── architecture-notes.md    -> ../../pages/00000065916.md
    ├── demo-plan.md             -> ../../pages/00000425985.md
    └── welcome-to-reposix.md    -> ../../pages/00000131192.md

.gitignore emission

Content is hard-coded /tree/\n (7 bytes). Inode 4 (GITIGNORE_INO), perm: 0o444, never writable — the kernel rejects write() at the VFS layer, and the FUSE write() callback also returns EROFS for InodeKind::Gitignore as belt-and-braces. The bytes come from a compile-time const GITIGNORE_BYTES: &[u8] = b"/tree/\n"; — no runtime input, no format! call, no content-injection path.

We assume the mount root is a virgin working tree created by reposix mount — the v0.4 design explicitly does NOT handle collision with a pre-existing user-authored .gitignore. If that bites in practice, Phase 14+ can address it.

Known limitations

  1. No Unicode NFC normalization (T-13-06). Two visually-identical titles that differ in NFC form (composed é vs decomposed é) will produce different slugs. Not worth the dependency budget (would pull deunicode or equivalent ~500KB) for the v0.4 read-only path. Acceptable for v0.4; reconsider if a real user hits it. Tracked as T-13-06 in the Phase-13 threat register.
  2. Tree does not live-refresh on backend change. The snapshot is rebuilt at each readdir("tree/") by re-listing from the backend (via the existing lazy-fetch path). If the backend changes between fetches, the mount shows the stale tree until the next readdir. This is consistent with v0.3's caching semantics.
  3. Confluence-only for v0.4. GitHub issues don't expose parent metadata; sim issues have no hierarchy field. Only Confluence overrides supports(BackendFeature::Hierarchy) to true, so tree/ is emitted only for --backend confluence. Sim and GitHub mounts show issues/
  4. .gitignore (with the same /tree/\n content, harmlessly inert).
  5. 500-page cap still applies. Phase 11 capped list_issues at 500 pages per invocation. TreeSnapshot::build consumes whatever list_issues returns, so spaces with >500 pages will render a truncated tree. OP-7 tracks paginated readdir as a future hardening.
  6. No write-through-tree beyond POSIX symlink semantics. Writes to tree/foo.md work because the kernel VFS resolves the symlink to pages/<id>.md transparently — no custom FUSE logic. But this also means mv tree/foo.md tree/bar.md (renaming a symlink) silently fails; renames in tree/ are not supported.

Consequences

  • Breaking. Every caller that read mount/<padded-id>.md now reads mount/<root_collection>/<padded-id>.md. Demos, docs, README, and tests are updated in the same release (v0.4.0). CHANGELOG.md lists the migration under ### BREAKING.
  • 11-digit id padding. Previously {:04}.md, now {:011}.md to accommodate astronomical Confluence page IDs without overflow and match TreeSnapshot::symlink_target() byte-for-byte.
  • Additive core change. The core Issue struct gains parent_id: Option<IssueId> with #[serde(default)] — legacy frontmatter files on disk still parse unchanged.
  • Writeable path unchanged. pages/ / issues/ support the same write semantics the flat layout had (which is to say, read-only for Confluence in v0.4). tree/foo.md writes via symlink — kernel VFS resolves to pages/<id>.md transparently, no custom FUSE logic.
  • Git-merge hell dissolves. Title renames and reparenting change only FUSE-synthesized symlinks, which are .gitignore'd. Two agents editing the same page body produce a standard single-file merge on the stable pages/<id>.md path.

References

  • .planning/phases/13-nested-mount-layout-pages-tree-symlinks-for-confluence-paren/13-CONTEXT.md — locked design handshake with user (2026-04-14 pre-sleep session)
  • .planning/phases/13-nested-mount-layout-pages-tree-symlinks-for-confluence-paren/13-RESEARCH.md — implementation research
  • .planning/phases/13-nested-mount-layout-pages-tree-symlinks-for-confluence-paren/13-C-SUMMARY.md — Wave C integrator summary (FUSE wiring)
  • HANDOFF.md §OP-1 — original scope statement
  • ADR-002 — superseded layout decision (flat layout); field-mapping sections remain authoritative
  • ADR-001 — sibling ADR, same read-path-only philosophy
  • crates/reposix-fuse/src/fs.rs — canonical implementation; if this ADR and the code disagree, the code wins and this ADR is stale
  • crates/reposix-core/src/path.rs — slugify_title + slug_or_fallback
